Kyocera TCG104SVLPAANN-AN20 10.4" TN LCM 800×600 450nits WLED LVDS 30pins

$0

Kyocera TCG104SVLPAANN-AN20 10.4" TN LCM 800600 450nits WLED LVDS 30pinsSpe

Product Description

Kyocera TCG104SVLPAANN-AN20 10.4" TN LCM 800×600 450nits WLED LVDS 30pins


System Category :LCD/OLED/EPD Flat Panel > TFT-LCD Panel
Brand :Kyocera
Series :TCG104SVLPAANN
Model :TCG104SVLPAANN-AN20
Keywords Desc. :Kyocera 10.4" TN LCM 800×600 450nits WLED LVDS 30pins
Product Class :Graphic Display
Product Tags :Color TFT-LCD
Application :Industrial
Panel Type :a-Si TFT-LCD
Panel Composition :LCM
Panel Size :10.4"
Resolution :800×600
Aspect Ratio :4:3 (W:H)
Form Factor :Flat Rectangle
Active Area :211.2 (W) × 158.4 (H) mm (A.A)
Outline Dimension :240.7 (W) × 180.2 (H) mm
Max. Depth :9.5 mm
LC Family :TN
Polarizer :Transmissive
Brightness :450 (Typ.)
Contrast Ratio :900:1 (Typ.)
Viewing Angle :80/80/80/60 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction :6 o'clock
Display Colors :262K/16.2M
Backlight Type :WLED
Interface Type :LVDS
Interface Pins :30 Pins
Touch Panel :Without
Operating Temp. :-20 ~ 70 °C
Storage Temp. :-30 ~ 80 °C
