SHARP LQ270M1LX01 27" VA LCM 1920×1200 500nits WLED LVDS 31pins

SHARP LQ270M1LX01 27" VA LCM 19201200 500nits WLED LVDS 31pinsSpecification

Product Description

SHARP LQ270M1LX01 27" VA LCM 1920×1200 500nits WLED LVDS 31pins

System Category :	LCD/OLED/EPD Flat Panel > TFT-LCD Panel
Brand :	Sharp
Series :	LQ270M1LX
Model :	LQ270M1LX01
Keywords Desc. :	Sharp 27" VA LCM 1920×1200 500nits WLED LVDS 31pins
Product Class :	Graphic Display
Product Tags :	Color TFT-LCD
Application :	Industrial
Panel Type :	a-Si TFT-LCD
Panel Composition :	LCM
Panel Size :	27"
Resolution :	1920×1200
Aspect Ratio :	16:10 (W:H)
Form Factor :	Flat Rectangle
Active Area :	581.76 (W) × 363.6 (H) mm (A.A)
Outline Dimension :	620 (W) × 407.6 (H) mm
Max. Depth :	23 mm
LC Family :	VA
Polarizer :	Transmissive
Brightness :	500 (Typ.)
Contrast Ratio :	1500:1 (Typ.)
Viewing Angle :	85/85/85/85 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction :	Symmetry
Display Colors :	16.7M
Backlight Type :	WLED
Interface Type :	LVDS
Interface Pins :	31 Pins
Touch Panel :	Without
Operating Temp. :	-15 ~ 75 °C
Storage Temp. :	-20 ~ 75 °C
