SHARP LQ057Q3DC12 5.7" TN LCM 320×240 500nits CCFL TTL 33pins

SHARP LQ057Q3DC12 5.7" TN LCM 320240 500nits CCFL TTL 33pinsSpecificationSy

Product Description

SHARP LQ057Q3DC12 5.7" TN LCM 320×240 500nits CCFL TTL 33pins

System Category :	LCD/OLED/EPD Flat Panel > TFT-LCD Panel
Brand :	Sharp
Series :	LQ057Q3DC
Model :	LQ057Q3DC12
Keywords Desc. :	Sharp 5.7" TN LCM 320×240 500nits CCFL TTL 33pins
Product Class :	Graphic Display
Product Tags :	Color TFT-LCD, Wide Temperature LCD
Application :	Industrial
Panel Type :	a-Si TFT-LCD
Panel Composition :	LCM
Panel Size :	5.7"
Resolution :	320×240
Aspect Ratio :	4:3 (W:H)
Form Factor :	Flat Rectangle
Active Area :	115.2 (W) × 86.4 (H) mm (A.A)
Outline Dimension :	144 (W) × 104.6 (H) mm
Max. Depth :	13.5 mm
LC Family :	TN
Polarizer :	Transmissive
Brightness :	500 (Typ.)
Contrast Ratio :	350:1 (Typ.)
Viewing Angle :	65/65/65/40 (Typ.)(CR≥5) (L/R/U/D)
Viewing Direction :	12 o'clock
Display Colors :	262K
Backlight Type :	CCFL
Interface Type :	TTL
Interface Pins :	33 Pins
Touch Panel :	Without
Operating Temp. :	-30 ~ 80 °C
Storage Temp. :	-30 ~ 80 °C
