SHARP LQ150X1LW71N 15" VA LCM 1024×768 250nits CCFL LVDS 20pins

SHARP LQ150X1LW71N 15" VA LCM 1024768 250nits CCFL LVDS 20pinsSpecification

Product Description

SHARP LQ150X1LW71N 15" VA LCM 1024×768 250nits CCFL LVDS 20pins

System Category :	LCD/OLED/EPD Flat Panel > TFT-LCD Panel
Brand :	Sharp
Series :	LQ150X1LW
Model :	LQ150X1LW71N
Keywords Desc. :	Sharp 15" VA LCM 1024×768 250nits CCFL LVDS 20pins
Product Class :	Graphic Display
Product Tags :	Color TFT-LCD
Application :	Industrial
Panel Type :	a-Si TFT-LCD
Panel Composition :	LCM
Panel Size :	15"
Resolution :	1024×768
Aspect Ratio :	4:3 (W:H)
Form Factor :	Flat Rectangle
Active Area :	304.128 (W) × 228.096 (H) mm (A.A)
Outline Dimension :	331.6 (W) × 254.76 (H) mm
Max. Depth :	13 mm
LC Family :	VA
Polarizer :	Transmissive
Brightness :	250 (Typ.)
Contrast Ratio :	400:1 (Typ.)
Viewing Angle :	85/85/85/85 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction :	Symmetry
Display Colors :	16.2M
Backlight Type :	CCFL
Interface Type :	LVDS
Interface Pins :	20 Pins
Touch Panel :	Without
Operating Temp. :	0 ~ 60 °C
Storage Temp. :	-25 ~ 60 °C
