AV123Z7M-N11 BOE 12.3" IPS LCD PANEL 1920×720 800nits WLED LVDS 41pins

AV123Z7M-N11 BOE 12.3" IPS LCD PANEL 1920720 800nits WLED LVDS 41pins

Product Description

System Category :	LCD/OLED/EPD Flat Panel > TFT-LCD Panel
Brand :	BOE
Series :	AV123Z7M
Model :	AV123Z7M-N11
Keywords Desc. :	BOE 12.3" IPS LCM 1920×720 800nits WLED LVDS 41pins
Product Class :	Graphic Display
Product Tags :	Color TFT-LCD, Wide Temperature LCD, High Brightness LCD, Sunlight Readable LCD, IPS LCD
Application :	Automotive Display
Panel Type :	a-Si TFT-LCD
Panel Composition :	LCM
Panel Size :	12.3"
Resolution :	1920×720
Aspect Ratio :	8:3 (W:H)
Form Factor :	Flat Rectangle
Active Area :	292.032 (W) × 109.512 (H) mm (A.A)
Outline Dimension :	307.9 (W) × 130.27 (H) mm
LC Family :	IPS
Polarizer :	Transmissive
Brightness :	800 (Typ.)
Contrast Ratio :	1000:1 (Typ.)
Viewing Angle :	80/80/80/80 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction :	Symmetry
Display Colors :	16.7M
Backlight Type :	WLED
Interface Type :	LVDS
Interface Pins :	41 Pins
Touch Panel :	Without
Operating Temp. :	-30 ~ 85 °C
Storage Temp. :	-40 ~ 90 °C
