LG Display 7" LB070WV8-SL01 LCD Panel 800×480 450nits WLED LVDS 30pins LB070WV8 Display Screen

LG Display 7" LB070WV8-SL01 LCD Panel 800480 450nits WLED LVDS 30pins LB070

Product Description

System Category :	LCD/OLED/EPD Flat Panel > TFT-LCD Panel
Brand :	LG Display
Series :	LB070WV8
Model :	LB070WV8-SL01
Keywords Desc. :	LG Display 7" IPS LCM 800×480 450nits WLED LVDS 30pins
Product Class :	Graphic Display
Product Tags :	Color TFT-LCD, Wide Temperature LCD, IPS LCD
Application :	Automotive Display, Industrial
Panel Type :	a-Si TFT-LCD
Panel Composition :	LCM
Panel Size :	7"
Resolution :	800×480
Aspect Ratio :	15:9 (W:H)
Form Factor :	Flat Rectangle
Active Area :	152.4 (W) × 91.44 (H) mm (A.A)
Outline Dimension :	170 (W) × 106.3 (H) mm
Max. Depth :	10.7 mm
LC Family :	IPS
Polarizer :	Transmissive
Brightness :	450 (Typ.)
Contrast Ratio :	800:1 (Typ.)
Viewing Angle :	89/89/89/89 (Min.)(CR≥10) (L/R/U/D)
Viewing Direction :	Symmetry
Display Colors :	16.2M
Backlight Type :	WLED
Interface Type :	LVDS
Interface Pins :	30 Pins
Touch Panel :	Without
Operating Temp. :	-30 ~ 80 °C
Storage Temp. :	-30 ~ 85 °C
