LG 31.5inch LB315WRM-SVA1 3840x2160 1000nit sRGB 1300:1 true 10bit Vby1 Case Top

$0

LG 31.5inch LB315WRM-SVA1 3840x2160 1000nit sRGB 1300:1 true 10bit Vby1 Case Top

Product Description

LG 31.5inch LB315WRM-SVA1 3840x2160 1000nit sRGB 1300:1 true 10bit Vby1 Case Top


  • Brand
  • LG Display
  • Model P/N
  • LB315WRM-SVA1
  • Diagonal Size
  • 32.0"
  • Panel Type
  • a-Si TFT-LCD, LCM
  • Resolution
  • 3840(RGB)×2160, UHD  139PPI
  • Pixel Format
  • RGB Vertical Stripe
  • Active Area
  • 697.306(W)×392.234(H) mm
  • Bezel Opening
  • -
  • Outline Dim.730.7(H)×425.2(V) mm
  • TreatmentAntiglare (Haze 25%), Hard coating (3H)
  • Luminance1000 cd/m² (Typ.)
  • Contrast Ratio1300:1 (Typ.) (TM)
  • View DirectionSymmetry
  • Response Time14 (Typ.)(G to G)
  • Viewing Angle89/89/89/89 (Typ.)(CR≥10)
  • Operating ModeIPS, Normally Black, Transmissive
  • Support Color1.07B   100% sRGB
  • Light SourceWLED , 30K hours , W/O Driver
  • Weight6.00/6.30Kgs (Typ./Max.)
  • Designed For
  • Frame Rate60Hz
  • Touch PanelWithout
  • Interface Type
  • V-by-One 8 lane , 51 pins Connector
  • Power Supply
  • 10V (Typ.)
  • Environment
  • Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C


LG Display LB315WRM-SVA1 Mechanical Details

Pixel Features :Resolution3840(RGB)×2160, UHDDot Pitch(mm)0.06053×0.18159 (H×V)
Pixel FormatRGB Vertical StripePixel Pitch(mm)0.18159×0.18159 (H×V)  [139PPI]
Mechanical Size :Active Area(mm)697.306(H) × 392.234(V)Bezel Area(mm)-
Outline Dim.(mm)730.7(H) × 425.2(V)Depth(mm)23 (Typ.)
Outline Features :Form StyleFlat RectangleOutline Shape
Aspect Ratio16:9 (H:V)OrientationLandscape type
Mounting :Rear mounting holes
Other Spec :Weight6.00/6.30Kgs (Typ./Max.)TreatmentAntiglare (Haze 25%), Hard coating (3H)
  • Disclaimer : Inputted by panelook engineers according to datasheet, but we cannot guarantee the spec listed is entirely correct.
  •  Back to Top

LG Display LB315WRM-SVA1 Optical Details

Basic Information :Luminance(cd/m²)1000 (Typ.)Contrast Ratio1300:1 (Typ.) (Transmissive)
Viewing Angle89/89/89/89 (Typ.)(CR≥10) Display ModeIPS, Normally Black, Transmissive
Best View onSymmetryResponse(ms)14 (Typ.)(G to G)
Color Performance :White CoordinateX:0.313; Y:0.329Display Colors1.07B (10-bit)
Color Temperature6485KWhite Uniformity1.33 (Max.)(9 points)
1931 Color Gamut :NTSC Ratio82%sRGB100% coverage
Adobe RGB81% coverageDCI-P385% coverage
Rec.202061% coverageRemarkssRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
Dispaly Performance :Outdoor VisibilitySunlight ReadableTransmissivity-
