LG 31.5inch LB315WRM-SVA2 3840x2160 1000nit sRGB 1000:1 true 10bit Vby1 Case Top

Product Description

LG 31.5inch LB315WRM-SVA2 3840x2160 1000nit sRGB 1000:1 true 10bit Vby1 Case Top


  • Brand
  • LG Display
  • Model P/N
  • LB315WRM-SVA2
  • Diagonal Size
  • 32.0"
  • Panel Type
  • a-Si TFT-LCD, LCM
  • Resolution
  • 3840(RGB)×2160, UHD  139PPI
  • Pixel Format
  • RGB Vertical Stripe
  • Active Area
  • 697.306(W)×392.234(H) mm
  • Bezel Opening
  • 702.3(W)×397.2(H) mm
  • Outline (mm)
  • 730.7×425.2 (H×V×D)
  • Treatment
  • Antiglare (Haze 25%), Hard coating (3H)
  • Luminance
  • 1000 cd/m² (Typ.)
  • Contrast Ratio
  • 1000 : 1 (Typ.) (TM)
  • Viewing Angle
  • 89/89/89/89 (Typ.)(CR≥10)
  • Response
  • 14 (Typ.)(G to G) ms
  • Good View at
  • Symmetry
  • Work Mode
  • IPS, Normally Black, Transmissive
  • Color Depth
  • 1.07B   100% sRGB
  • Backlight
  • 5 strings WLED , 30K hours , No Driver
  • Mass
  • 6.00/6.30Kgs (Typ./Max.)
  • Used for
  • Refresh Rate
  • 60Hz
  • Touchscreen
  • Without
  • Signal Type
  • V-by-One 8 lane , Connector 51 pins
  • Voltage Supply
  • 10V (Typ.)
  • Max. Ratings
  • Storage Temp.: -20 ~ 60 °C    Operating Temp.: 0 ~ 50 °C

  • LG Display LB315WRM-SVA2 Mechanical Details

    Pixel Features :Resolution3840(RGB)×2160, UHDDot Pitch(mm)0.06053×0.18159 (H×V)
    Pixel FormatRGB Vertical StripePixel Pitch(mm)0.18159×0.18159 (H×V)  [139PPI]
    Mechanical Size :Active Area(mm)697.306(H) × 392.234(V)Bezel Area(mm)702.3(H) × 397.2(V)
    Outline Dim.(mm)730.7(H) × 425.2(V)Depth(mm)23 (Typ.)
    Outline Features :Form StyleFlat RectangleOutline Shape
    Aspect Ratio16:9 (H:V)OrientationLandscape type
    Mounting :Rear mounting holes
    Other Spec :Weight6.00/6.30Kgs (Typ./Max.)TreatmentAntiglare (Haze 25%), Hard coating (3H)
    • Disclaimer : Inputted by panelook engineers according to datasheet, but we cannot guarantee the spec listed is entirely correct.
    •  Back to Top

  • LG Display LB315WRM-SVA2 Optical Details

    Basic Information :Luminance(cd/m²)1000 (Typ.)Contrast Ratio1000:1 (Typ.) (Transmissive)
    Viewing Angle89/89/89/89 (Typ.)(CR≥10) Display ModeIPS, Normally Black, Transmissive
    Best View onSymmetryResponse(ms)14 (Typ.)(G to G)
    Color Performance :White CoordinateX:0.313; Y:0.329Display Colors1.07B (10-bit)
    Color Temperature6485KWhite Uniformity1.33 (Max.)(9 points)
    1931 Color Gamut :NTSC Ratio82%sRGB100% coverage
    Adobe RGB81% coverageDCI-P385% coverage
    Rec.202061% coverageRemarkssRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
    Dispaly Performance :Outdoor VisibilitySunlight ReadableTransmissivity-
