LG 27inch 3840x2160 LM270WR9-SSA1 HDR400 DCI 98% 2000:1 8bF LBL

$0

LG 27inch 3840x2160 LM270WR9-SSA1 HDR400 DCI 98% 2000:1 8bF LBLBrandLG DisplayMo

Product Description

LG 27inch 3840x2160 LM270WR9-SSA1 HDR400 DCI 98% 2000:1 8bF LBL


  • Brand
  • LG Display
  • Model P/N
  • LM270WR9-SSA1
  • Diagonal Size
  • 27.0"
  • Panel Type
  • a-Si TFT-LCD, LCM
  • Resolution
  • 3840(RGB)×2160, UHD  163PPI
  • Pixel Format
  • RGB Vertical Stripe
  • Active Area
  • 596.736(W)×335.664(H) mm
  • Bezel Opening
  • -
  • Outline Dim.608.8(H)×349.4(V)×15.3(D) mm
  • TreatmentAntiglare (Haze 25%), Hard coating (3H)
  • Luminance400 cd/m² (Typ.)
  • Contrast Ratio2000:1 (Typ.) (TM)
  • View DirectionSymmetry
  • Response Time14 (Typ.)(G to G)
  • Viewing Angle89/89/89/89 (Typ.)(CR≥10)
  • Operating ModeIPS, Normally Black, Transmissive
  • Support Color1.07B   97% DCI-P3
  • Light SourceWLED  [19S4P] , 30K hours , W/O Driver
  • Weight2.45/2.57Kgs (Typ./Max.)
  • Designed For
  • Frame Rate60Hz
  • Touch PanelWithout
  • Interface Type
  • eDP (4 Lanes) , HBR2 (5.4G/lane) , 30 pins Connector
  • Power Supply
  • 10V (Typ.)
  • Environment
  • Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C

LG Display LM270WR9-SSA1 Mechanical Details

Pixel Features :
Pixel Format
3840(RGB)×2160, UHD
Dot Pitch
0.0518×0.1554 mm (H×V)
Configuration
RGB Vertical Stripe
Pixel Pitch
0.1554×0.1554 mm (H×V)  [163PPI]
Mechanical Size :
Display Area
596.736×335.664 mm (H×V)
Bezel Area
-
Outline Dim.
608.8×349.4 mm (H×V)
Outline Depth
9.5/15.3 (Typ./Max.) mm
Outline Features :
Form Factor
Flat Rectangle
Orientation
Landscape type
Aspect Ratio
16:9 (H:V)
Shape Style
4-side borderless
Holes & Brackets :
Rear mounting holes
Other Features :
Weight
2.45/2.57Kgs (Typ./Max.)
Surface
Antiglare (Haze 25%), Hard coating (3H)
  • Disclaimer : Inputted by panelook engineers according to datasheet, but we cannot guarantee the spec listed is entirely correct.
  •  Back to Top

LG Display LM270WR9-SSA1 Optical Details

Basic Information :
Brightness
400 cd/m² (Typ.), HDR400
Contrast Ratio
2000:1 (Typ.) (Transmissive)
Viewing Angle
89/89/89/89 (Typ.)(CR≥10)
Optical Mode
IPS, Normally Black, Transmissive
Viewing Direction
Symmetry
Response Time
14 (Typ.)(G to G) ms
Color Performance :
Chromaticity
Wx:0.313; Wy:0.329
Color Numbers
1.07B (8-bit + Hi-FRC)
Color Temperature
6485K
Uniformity
1.33 (Max.)(9 points)
1931 Color Gamut :
NTSC Ratio
95%
sRGB
100% coverage
Adobe RGB
88% coverage
DCI-P3
97% coverage
Rec.2020
71% coverage
Remarks
sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
