LG 27inch 3840x2160 LM270WR8-SSE1 HDR1000 DCI 98% 1000:1 8bF 144Hz Neo lll MINI LED ATW

$0

LG 27inch 3840x2160 LM270WR8-SSE1 HDR1000 DCI 98% 1000:1 8bF 144Hz Neo lll MINI

Product Description

LG 27inch 3840x2160 LM270WR8-SSE1 HDR1000 DCI 98% 1000:1 8bF 144Hz Neo lll MINI LED ATW


  • Brand
  • LG Display
  • Model P/N
  • LM270WR8-SSE1
  • Diagonal Size
  • 27.0"
  • Panel Type
  • Oxide TFT-LCD, LCM
  • Resolution
  • 3840(RGB)×2160, UHD  163PPI
  • Pixel Format
  • RGB Vertical Stripe
  • Active Area
  • 596.736(W)×335.664(H) mm
  • Bezel Opening
  • -
  • Outline Size
  • 604.06(W)×347.38(H) ×21.54(D) mm
  • Surface
  • Antiglare (Haze 25%), Hard coating (3H)
  • Brightness
  • 740 cd/m² (Typ.)
  • Contrast Ratio
  • 1000:1 (Typ.) (TM)
  • Viewing Angle
  • 89/89/89/89 (Typ.)(CR≥10)
  • Display Mode
  • IPS, Normally Black, Transmissive
  • Best View on
  • Symmetry
  • Response Time
  • 4 (Typ.)(G to G)
  • Display Colors
  • 1.07B   100% DCI-P3
  • Lamp Type
  • Mini LED , 30K hours , Without Driver
  • Frequency
  • 144Hz
  • Touch Screen
  • Without
  • Panel Weight
  • 3.60/3.78Kgs (Typ./Max.)
  • Application
  •
  • Signal Interface
  • eDP (16 Lanes) , HBR2 (5.4G/lane) , 120 pins Connector
  • Input Voltage
  • 10.0V (Typ.)
  • Environment
  • Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C

  • LG Display LM270WR8-SSE1 Mechanical Features

    Screen Size :27.0"
    Pixel Features :Pixel NumberPixel FormatDot Pitch (H×V)Pixel Pitch (H×V)
    3840(RGB)×2160, UHDRGB Vertical Stripe0.0518×0.1554 mm0.1554×0.1554 mm  [163PPI]
    Mechanical Size :Display Area (H×V)Bezel Opening (H×V)Overall Dimension (H×V)Overall Depth
    596.736×335.664 mm-604.06×347.38 mm18.89/21.54 (Typ./Max.) mm
    Outline Features :Form ShapeAspect Ratio (H:V)OrientationShape Style
    Flat Rectangle16:9Landscape type4-side borderless
    Other Spec :MassPanel CoverSurface Treatment
    3.60/3.78Kgs (Typ./Max.)-Antiglare (Haze 25%), Hard coating (3H)
    Holes & Brackets :Rear mounting holes
    • Disclaimer : Inputted by panelook engineers according to datasheet, but we cannot guarantee the spec listed is entirely correct.
    •  Back to Top

  • LG Display LM270WR8-SSE1 Optical Features

    Basic Information :LuminanceWork ModeContrast Ratio
    740 cd/m² (Typ.), HDR1000IPS, Normally Black, Transmissive1000:1 (Typ.) (Transmissive)
    Good View atViewing AngleResponse Time
    Symmetry89/89/89/89 (Typ.)(CR≥10)4 (Typ.)(G to G) (ms)
    Dispaly Color :Color Temperature:Support ColorColor Coordinate
    6485K1.07B (8-bit + Hi-FRC)X:0.313; Y:0.329
    1931 Color Gamut :NTSC RatiosRGB CoverageAdobe RGB Coverage
    98%100%88%
    DCI-P3 CoverageRec.2020 CoverageRemarks
    100%73%sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
    White Uniformity :1.33 (Max.)(9 points)
    Performance :3D TechnologyOutdoor VisibilityReflectance
    -Sunlight Readable-
