Hitachi KOE TX16D207VM0BAA 6.2" IPS LCM 640×240 400nits WLED LVDS 20pins

Hitachi KOE TX16D207VM0BAA 6.2" IPS LCM 640240 400nits WLED LVDS 20pinsSpec

Product Description

Hitachi KOE TX16D207VM0BAA 6.2" IPS LCM 640×240 400nits WLED LVDS 20pins

System Category :	LCD/OLED/EPD Flat Panel > TFT-LCD Panel
Brand :	KOE
Series :	TX16D207
Model :	TX16D207VM0BAA
Keywords Desc. :	KOE 6.2" IPS LCM 640×240 400nits WLED LVDS 20pins
Product Class :	Graphic Display
Product Tags :	Color TFT-LCD, IPS LCD
Application :	Industrial
Panel Type :	a-Si TFT-LCD
Panel Composition :	LCM
Panel Size :	6.2"
Resolution :	640×240
Aspect Ratio :	8:3 (W:H)
Form Factor :	Flat Rectangle
Active Area :	148.8 (W) × 53.76 (H) mm (A.A)
Outline Dimension :	173 (W) × 70 (H) mm
Max. Depth :	7 mm
LC Family :	IPS
Polarizer :	Transmissive
Brightness :	400 (Typ.)
Contrast Ratio :	1200:1 (Typ.)
Viewing Angle :	85/85/85/85 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction :	Symmetry
Display Colors :	262K
Backlight Type :	WLED
Interface Type :	LVDS
Interface Pins :	20 Pins
Touch Panel :	Without
Operating Temp. :	-20 ~ 70 °C
Storage Temp. :	-30 ~ 80 °C
