Hitachi KOE TX18D211VM0BXA 7" IPS LCM 800×480 1000nits WLED LVDS 20pins CTP 5.0G Vibration

Hitachi KOE TX18D211VM0BXA 7" IPS LCM 800480 1000nits WLED LVDS 20pins CTP

Product Description

Hitachi KOE TX18D211VM0BXA 7" IPS LCM 800×480 1000nits WLED LVDS 20pins CTP 5.0G Vibration

System Category :	LCD/OLED/EPD Flat Panel > TFT-LCD Panel
Brand :	KOE
Series :	TX18D211
Model :	TX18D211VM0BXA
Keywords Desc. :	KOE 7" IPS LCM 800×480 1000nits WLED LVDS 20pins CTP 5.0G Vibration
Product Class :	Graphic Display
Product Tags :	Color TFT-LCD, Wide Temperature LCD, High Brightness LCD, Capacitive Touch LCD, Sunlight Readable LCD, IPS LCD
Application :	Automotive Display, Industrial, Outdoor High Brightness, Rugged Industry
Panel Type :	LTPS TFT-LCD
Panel Composition :	LCM
Panel Size :	7"
Resolution :	800×480
Aspect Ratio :	15:9 (W:H)
Form Factor :	Flat Rectangle
Active Area :	152.4 (W) × 91.44 (H) mm (A.A)
Outline Dimension :	170 (W) × 113.3 (H) mm
Max. Depth :	22 mm
LC Family :	IPS
Polarizer :	Transmissive
Brightness :	1000 (Typ.)
Contrast Ratio :	1000:1 (Typ.)
Viewing Angle :	85/85/85/85 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction :	Symmetry
Display Colors :	262K
Backlight Type :	WLED
Interface Type :	LVDS
Interface Pins :	20 Pins
Touch Panel :	PCAP
Operating Temp. :	-30 ~ 80 °C
Storage Temp. :	-40 ~ 90 °C
